We fabricate the bodies from 3/16" aluminum plate
for light weight and super strength. This provides fluid motion for years of comfortable quilting.
Sealed bearings on the drive shafts do not need lubrication
for a lifetime of smooth operation.
Four oil wicks to the moving parts of the head need only one
drop of sewing oil every 8 hours of sewing.
The external brush, 90 volt DC motor is mounted inside the
body of the machine, keeping it away from your ears and hair while sewing.
The machine plugs into standard 110 volt AC wall outlet.
No special wiring is needed.
The hopping foot moves over seams and a variety of materials
for quality stitches. The foot is also perfectly round for sewing with rulers or templates.
The handles are located out of your line of sight. Their vertical placement is ergonimically
correct and provides stress free operation.
The focusable laser stylus is built to be located either on the front or rear of the sewing
head for either linear or single cell patterns.
We inject expanding foam inside the body cavity to reduce vibration and noise for comfortable
sewing.
The flourescent light is placed for excellent visibility. It can be replaced with an
optional blacklight for use with hidden glow powder or pencils for your unique designs.
The standard variable speed controller is infinitely adjustable for just the right speed of
operation.
The optional Needle Positioner by Intellistitch* is available with needle up or down, variable
speed control, single stitch and repeating single stitch.
The optional Stitch Regulator 1s2KN by Intellistitch* includes all the features of the Needle
Positioner plus variable stitch lengths from 1 to 12 per inch, variable speed control with motion detector, single stitch,
repeating single stitch and precision quilting mode.
The all steel table comes in two piece construction, making it easy to place in hard to reach
rooms. All tables can be made in a variety of lengths (inquire about specail lengths).
The tracks enclose the wheels for solid, smooth motion. This also protects your quilts from
marks if they fall on the track.
Our cord chain keeps the electrical cord out from under your feet while sewing on the pantograph
side of the table, allowing you to concentrate on the pattern.
The fabric rollers are positioned to provide easy access to change the bobbin without moving
from your location on the quilt.
Quilting while seated is comfortable for the operator.
The roller lift holds up the quilt top roller so you can have access to the batting between
the layers of the quilt.
All tables come with leg levels, allowing for your custom height adjustment. Hydraulic
lift legs are available as an option.
The ratchet action advances the takeup roller quickly and easily.
The solid wheels are fixed to axles with sealed bearings mounted on the axle for non-binding
movement.
The solid wheels are fixed to axles with sealed bearings mounted on the axle for non-binding
movement.
A roller is included for storing large rolls of batting under the table.
Easy to engage track locks help sew horitzontal and vertical straight lines.
All new Nolting Longarms are predrilled for attaching the popular circle and diagonal line
maker Hartly Fence and Circle Lord.
All commercial Nolting Longarm Quilting Machines can be equipped with any of the available
options for a custom system to meet your specific needs.
